HH Electronics TNi-C4-WH HH TESSEN INSTALL - TNi-C4 - 4 inch ceiling speaker - 70/100V 3 power tappings - WHITE
The Tessen TNi-C4 delivers premium audio reinforcement. Designed with the installer in mind, The TNi-C4 – 4" coaxial ceiling speaker - features a 6x position power tap selector located under the front steel grille, providing swift output adjustment once installed. With connectivity for 70V/100V and 8Ω low impedance lines, The TNi-C4 delivers a highly flexible solution. The spring connection terminals ensure leads are secure after the speaker is fitted.
| Model: HH-HHE-TNi-C4-WH |
| Speaker Type: 2-way coaxial ceiling speaker |
| LF Driver: 4-inch paper cone woofer |
| HF Driver: 1.5-inch Neodymium tweeter |
| Frequency Response (-10dB): 85Hz - 20kHz |
| Frequency Response (-3dB): 100Hz - 16kHz |
| Power (Low Impedance): 45W AES, 180W Peak (at 8Ω) |
| 100V Power Taps: 30W, 15W, 6W |
| 70V Power Taps: 15W, 7.5W, 3W |
| Max SPL (Peak): 111 dB (at 1m) |
| Construction: ABS Plastic housing, steel grille |
| Finish: White |
| Cutout Diameter: 180mm (7.1 inches) |
| Mounting Depth: 156mm (6.1 inches) |
| Mounting Points: 3x "dog ear" brackets |
| Input Connector: Push spring connectors |
